技術特點

技術特點:

1. 干燥溫度低、能耗低、無污染、連續生產、自動控制、滿足GMP要求；

2. 低溫干燥，并隨物系的不同可調（35℃,90℃）;

3. 產品干燥過程有一定程度的結晶，粉碎后粒料流動性好，可以直接灌膠囊；

4. 進料速度可精確調整，即使在進料量很小的情況下，布料裝置也能均勻布料；

5. 箱體內各條傳送帶分別由變頻電機單獨控制；

6. 自動制粒，真空狀態連續排出干顆粒至儲料桶內，可在自動干燥過程中更換干顆粒儲料桶；

7. 能耗小、低噪音；

8. 設備可CIP在位清洗，有很高的衛生程度；

9. 傳送帶運動采用變頻調速電機控制，具有糾偏和張力調節功能；

10. 配置罐帶有攪拌裝置和恒溫裝置，在添加輔料時可以加熱混合；

11. 基于PC的控制系統，人機界面友好，操作方便，靈活修改過程參數；

12. 傳送帶有1層到10層多種規格，根據用戶的要求量身訂做；

13. 不同干燥方法比較。

TECHNICAL FEATURES

1. Low drying temperature, low energy consumption, no pollution, continuous production, automatic control, meeting GMP requirements.

2. Low temperature drying, adjustable according to different materials (35℃, 90℃).

3. Certain crystallization may occur during the drying process. After pulverization, the powder will have good fluidity and can be directly used for capsule filling.

4. The feeding speed can be precisely adjusted. Even when the feeding volume is very low, the material spreading device still can spread the materials evenly.

5. Each conveyor belt in the tank body can be separately controlled by the frequency converter motor.

6. Automatic granulation. Under the vacuum status, the dry granules are continuously discharged to the material storage barrel. The material storage barrel can be changed during the automatic drying process.

7. Low energy consumption and low noise.

8. The equipment can realize CIP in-place cleaning to achieve high sanitary degree.

9. The conveyor belt movement is controlled by frequency conversion speed adjustment motor, which is provided with functions of deviation correction and tension adjustment.

10. The dispensing tank is provided with blending device and constant temperature device. Heating and blending can be carried out when the auxiliary materials are added.

11. The control system based on PC has friendly human-machine interface and the operation is convenient. The process parameters can be flexibly modified.

12. The conveyor belts have various specifications ranging from 1 layer to 10 layers, which can be customized according to users' requirements.

13. Comparison between different drying methods.
